AUDIOCONTROL LC2iPRO BLACK 2 CHANNEL LINE OUTPUT CONVERTER W/ ACCUBASS AND ACR-1 LEVEL CONTROL

AudioControl

  • $ 129.95
    Unit price per

Only 4 left!

  • Car Audio 2-Channel Line Output Converter with AccuBASS® and Impedance Matching (ACR-1 remote included)
  • Two channels of active speaker level inputs (up to 40V input handling)
  • Fixed and variable outputs with discrete level controls
  • AccuBASS® processing for correction of bass roll-off
  • Load Selection Switch
  • GTO Signal Sensing
  • Ground Isolation Switch
  • ACR-1 dash remote inluded
  • Compact design

  • Inputs
    • Speaker Level Input: 1 (2 channels)
    • Maximum Speaker Level Input: 40 Vrms / 400 W (20kΩ setting)
    • Input Impedance (selectable): 20Ω, 60Ω, 20kΩ
  • Outputs
    • Preamp Outputs: 2 (2 channels main, 2 channels bass)
    • Maximum Output Level: 9.5Vrms/13V peak
    • Output Gain: +/- 12 dB
    • Output Impedance: 150Ω
  • Performance
    • Total Harmonic Distortion: 0.01%
    • Signal to Noise: >110 dB
    • Frequency Response: 20 Hz – 50 kHz ±1 dB
  • Control
    • Remote In / GTO™ Signal Sense / Audio Sense
    • 12VDC Remote Out (always active when unit is on)
  • General
    • Current Draw: 200 mA
    • Recommended Fuse Rating: 1 A
    • weights & dimensions
    • Dimensions: 6.9″L x 3″D x 1″H (including speaker connectors)
    • Weight: 0.75 lbs. (0.34 kg)
