Audiopipe EQ-710HL 7-Band Graphic Equalizer with High/Low 9V Line Driver (NEW)

Audiopipe 7-Band Graphic Equalizer with Hi/Lo 9V Line Driver
Model: EQ-710HL
Nickel Plated Locking Adjustable Knob
Hi/Lo Convertor
Adjustable Subwoofer Frequency
Easy Installation
Active Gain Pre-Amplifier
Individual Left and Right Sensitivity Controls for Auxiliary Input
Gold-plated RCA Input Connectors
Three Stereo RCA Outputs
Main / Auxiliary Input Selector

SPECIFICATIONS
Subwoofer output and level controls
Adjustable Subwoofer Frequency: 60Hz/90Hz
Gold-plated RCA in/Output connectors
Fader, Volume & Sub Controls
Main/Auxiliary input selector
3.5mm Front Audio Input
Preamp Outputs: Front/Rear/Sub
Graphic Center Frequencies: 50Hz, 125Hz, 315hz, 750Hz, 2.2kHz, 6kHz, 16kHz
Boost/Cut: 12dB
Sub Woofer Crossover: 60/90 Hz
S/N Ratio: 100dB
Frequency Response: 10Hz-50kHz +/-1dB
Maximum Output Voltage: 9V
THO: 0.005%
Input Sensitivity: 50MV – 3V
