PLANET AUDIO TR1500.1M CLASS A/B MONOBLOCK CAR AMPLIFIER
- Car Audio Class-A/B 2 ohm Stable Monoblock Amplifier
- Model: TR1500.1M
- RMS Power Rating:
- 4 ohms: 563 watts x 1 chan.
- 2 ohms: 1125 watts x 1 chan.
- Total power output: 1500 watts
- Pulse Width Modulated MOSFET power supply
- Wired remote bass level control included
- LED power (green) and protect (red) indicators
- Blue Illuminated Planet Audio Logo
- Soft start turn-on
- Mono channel operation
- Speaker-level (high-level) inputs
- 3-way protection circuitry (thermal, overload, and speaker short protection)
- Heavy duty aluminum alloy heat-sink
- Input sensitivity:
- Low level: 100mV - 2V
- High level: 2V - 8V
- Frequency Response: 20 - 20000 Hz
- Signal to Noise Ratio: 84 dB
- Variable low-pass filter: 50 - 250
- Variable Bass Boost: 0 to +18 dB bass boost
- Fuse Rating: 30A x 1
- Dimensions: 10" x 10.66" x 2.41"
- 4 gauge power and ground wiring is recommended for installation. Sold Separately.
