Sundown Audio NS-Series 10" NS6 V6 3000W RMS Power DVC 1 Ohm Car Subwoofer (NEW)
Sundown Audio NS-Series Version 6 10-inch DVC Car Subwoofer
Model: NS V.6 10" D1
3,000-Watt RMS
Dual 1 ohm voice coils
Custom tooled basket
Custom-tooled ultra-linear spider packs
Extended shorting ring
Eight-layer voice coil
Custom tooled basket
Cast aluminum cooling ring
Ultra-linear spider pack
Unique air exchanging system forces hot air out and cool air in
Aluminum vent ring
Ultra-linear Mega Roll V2 surround
SPECIFICATIONS
RE (Ohms): 1.8759
FS (Hz): 44.386
VAS (L): 6.2193
Qes: 0.5400
Qms: 5.4793
Qts: 0.4916
Le (mH): 1.6541
BL (NA): 19.5266
Mms (Grams): 393.5975
Cms (uM/N): 32.6651
Sens (dB @ 1w/1m): 81.7782
Xmax: 35mm
ENCLOSURE SPECIFICATIONS RECOMMENDATION
Sealed Enclosure: Not Recommended
Ported Enclosure: 1.5 cu.ft. net
Recommended Tuning: 32 Hz
Recommended Port Area: 22 sq.in.
Displacement: .23 cu. ft.
Depth: 12.24"
Outside Diameter: 11.81"
Cut-Out: 10.1"
